Phoebus: maintaining the smallest molecule within the Universe contained

Phoebus is a European Area Company (ESA) venture along with ArianeGroup and MT Aerospace. It goals to evaluate the feasibility and advantages of changing the metallic tanks on ESA’s Ariane 6 higher stage with carbon-fibre reinforced-plastic tanks. Whereas this light-weight materials presents the potential for saving a number of tonnes of mass, such an strategy has by no means been applied earlier than and presents vital technical challenges.

The central core of ESA’s Ariane 6 rocket runs of liquid oxygen and liquid hydrogen, that are two very completely different molecules, so the Phoebus venture must develop and produce two forms of tanks in a position to face up to extremes. This text focusses on progress made on the hydrogen tank, different Phoebus information is linked on the finish of this text.

Let it freeze

Hydrogen is the smallest molecule within the Universe, and when used as gasoline on the Ariane 6 rocket it needs to be cooled to −253 °C, simply 20 levels above absolute zero, the coldest temperature within the Universe.

Typically, carbon fibre composites don’t prefer it that chilly, like your pores and skin in winter. With the chilly your pores and skin will get dry and brittle such that if you transfer it will probably crack. This is identical for carbon fibre tanks: when stuffed with cool propellants beneath stress, small cracks can type which isn’t what you need on a rocket tank.

With these excessive situations the Phoebus venture group overcame many technical hurdles – not solely on improvement and tank ideas but in addition on measurement – there aren’t any off-the-shelf units that precisely measure miniscule leak charges at cryogenic temperatures as little as –253 °C.

Phoebus has already proved it’s doable: small 60-l demonstration ‘bottle’ tanks have proven that carbon-fibre reinforced-plastic can maintain hydrogen in liquid type – with out leaking.

Growing the ice-cold stress to cracking level

Now the Phoebus group is engaged on a bigger model with an up to date design that may maintain virtually 2600 litres. This 2-metre diameter hydrogen tank might be examined by filling it with hydrogen subsequent 12 months.

The tank accomplished the primary manufacturing steps on its inside tank stress vessel at MT Aerospace in Augsburg, Germany in September 2025 with manufacturing anticipated to be completed in December. ArianeGroup might be accountable for the testing and their engineers are engaged on the design of the take a look at facility.

A take a look at marketing campaign is deliberate in April subsequent 12 months. Regardless of being saved at –253 °C hydrogen catches hearth very simply so wants cautious dealing with, particular expertise and strict security guidelines to verify all the pieces goes easily.  The testing might be performed at a take a look at website of ArianeGroup in Trauen, Germany. The tank might be pushed step-by-step to its breaking level, creating the cracking impact however no additional: the group will cease earlier than reaching the whole failure level of the tank. The work on the brand new take a look at website kicked-off in February 2025, with a preliminary design confirmed in June 2025. A crucial design assessment by the top of this 12 months will permit for the beginning of the civil works on the website.

A number of checks might be run to try to be taught as a lot as doable about how the tank behaves as it might on the launch pad and through liftoff to know how and the place the primary cracks might seem. Sensors on and within the tank will present stress, temperature and pressure knowledge to observe throughout testing and evaluated in-depth between every take a look at.

Phoebus is a part of ESA’s Future Launchers Preparatory Programme (FLPP), that helps develop the know-how for future for area transportation methods. By conceiving, designing and investing in know-how that doesn’t exist but, this programme is lowering the danger entailed in creating untried and unproven initiatives for area.
